This is a packet of four Carbon Film Resistors (CFR). The resistance of each is 1 Ohm and the rated power is 2W. The main function of carbon film resistors is to reduce the current flow in a circuit. It can be used for current limiting, voltage division, resistance matching, load and capacitor matching.Because this resistor is made up of pure carbon, it has a high negative temperature coefficient. This means as temperature increases, the resistance decreases.

Product Image

Specifications of 1 Ohm, 2 Watt Resistor

• High Accuracy
• Good high-frequency characteristics
• Resistance:- 1 Ohm
• Rated Power :- 2W
• Tolerance:- 5%
• Tin-plated Copper leads
• Excellent long-term stability
• Has a Negative Temperature Coefficient
• Mounting Type: Through-hole(PTH)
• Type: Carbon Film(CFR)

Additional Resources

• Colour Coding of a Resistor

Package Includes

1 x1 Ohm, 2 Watt Resistor (Pack of 4)
