This 112.5 KVA three-phase transformer steps down 480V Delta to 208Y/120V the most common voltage conversion for commercial and industrial facilities. Whether you’re feeding 208V three-phase equipment from a 480V service or providing 120V single-phase branch circuits, this dry-type transformer handles it with continuous-duty reliability.

Made in USA UL Listed 112.5 KVA Capacity Ships from Stock 112.5 KVA Transformer Specifications

What’s Included

• 112.5 KVA Dry-Type Transformer (480V to 208Y/120V)
• NEMA 3R Enclosure (indoor/outdoor rated)
• Wall-Mount Brackets
• Primary & Secondary Terminal Connections
• Documentation & Wiring Instructions

Why This Transformer

480V to 208Y/120V Step-Down

Converts 480V three-phase Delta to 208Y/120V providing both 208V three-phase and 120V single-phase from a single transformer.

Continuous Duty Rated

Built for 24/7 industrial operation. Class H insulation handles high ambient temperatures without derating.

UL Listed & CSA Certified

Meets all applicable UL and CSA standards for safety and performance. Passes inspection without questions.

Quiet Operation

Sound level at or below 45 dB quieter than a normal conversation. Install near work areas without noise complaints.

Common Applications

Commercial Buildings Machine Shops HVAC Systems Lighting Panels Data Centers Manufacturing Warehouses (800) 417-6568

Need help sizing a transformer? Our engineers will match the right KVA to your load.

This 112.5 KVA dry-type transformer converts 480V three-phase Delta power to 208Y/120V, providing both three-phase 208V and single-phase 120V outputs from a single unit. It’s the standard voltage conversion for commercial buildings, industrial facilities, and machine shops that receive 480V service but need 208/120V for equipment, lighting, and receptacles.

Dry-type transformers require no oil filling or maintenance just install, wire, and forget. The NEMA 3R enclosure allows indoor or outdoor installation. Whether you’re building out a new shop or adding capacity to an existing facility, this transformer delivers reliable voltage conversion for the long haul.

Not sure what KVA rating you need? Call (800) 417-6568 our team will calculate the right transformer size based on your panel schedule and connected loads.
