Specifications:

• Product Family: AMD Ryzen Processors
• Product Line: AMD Ryzen 5 Desktop Processors
• Consumer Use: Yes
• Regional Availability: Global, China, NA, EMEA, APJ, LATAM
• Former Codename: “Vermeer”
• Architecture: “Zen 3”
• CPU Cores: 6
• Multithreading (SMT): Yes
• Threads: 12
• Max. Boost Clock: Up to 4.4GHz
• Base Clock: 3.5GHz
• L1 Cache: 384KB
• L2 Cache: 3MB
• L3 Cache: 32MB
• Default TDP: 65W
• Processor Technology for CPU Cores: TSMC 7nm FinFET
• Processor Technology for I/O Die: 12nm (Globalfoundries)
• CPU Compute Die (CCD) Size: 74mm
• I/O Die (IOD) Size: 125mm
• Package Die Count: 2
• Unlocked for Overclocking: Yes
• CPU Socket: AM4
• Socket Count: 1P
• Supporting Chipsets:
• X570
• X470
• X370
• B550
• B450
• B350
• A520
• CPU Boost Technology: Precision Boost 2
• Instruction Set: x86-64
• Supported Extensions: AES, AMD-V, AVX, AVX2, FMA3, MMX(+), SHA, SSE, SSE2, SSE3, SSE4.1, SSE4.2, SSE4A, SSSE3, x86-64
• Thermal Solution (PIB): AMD Wraith Stealth
• Max. Operating Temperature (Tjmax): 90C
• OS Support:

• Windows 11 – 64-Bit Edition
• Windows 10 – 64-Bit Edition
• RHEL x86 64-Bit
• Ubuntu x86 64-Bit

Connectivity

• USB Type-C Support: Yes
• Native USB 3.2 Gen 2 (10Gbps) Ports: 4
• Native USB 3.2 Gen 1 (5Gbps) Ports: 0
• Native USB 2.0 (480Mbps) Ports: 0
• Native SATA Ports: 2
• PCI Express Version: PCIe 4.0
• Native PCIe Lanes (Total/Usable): 24/20
• Additional Usable PCIe Lanes from Motherboard:
• AMD X570: 16x Gen 4
• AMD X470: 2x Gen 3
• AMD X470: 8x Gen 2
• NVMe Support: Boot, RAID0, RAID1, RAID10
• System Memory Type: DDR4
• Memory Channels: 2
• Max. Memory: 128GB
• System Memory Subtype: UDIMM
• System Memory Specification: Up to 3200MHz
• Max Memory Speed:
• 2x1R: DDR4-3200
• 2x2R: DDR4-3200
• 4x1R: DDR4-2933
• 4x2R: DDR4-2667
• ECC Support: Yes (Requires mobo support)

Graphics Capabilities:

• Integrated Graphics: No
• Graphics Model: Discrete Graphics Card Required

Key Features / Supported Technologies

• AMD StoreMI Technology
• AMD “Zen 3” Core Architecture
• AMD Ryzen VR-Ready Premium
