Audix ADS48 Antenna Distribution System

WIRELESS MICROPHONE ACCESSORY ANTENNA DISTRIBUTION SYSTEM COMBINES 4 TWO CHANNEL SYSTEMS (8 CHANNELS) WITH ONE SET OF ANTENNAS AND ONE POWER SUPPLY

The Audix ADS48 is a wide range UHF antenna distribution system that combines up to four wireless systems to be able to run off a single pair of antennas and power supply. The ADS48 has an internal switching power supply which eliminates the need for the individual DC power supplies normally needed for each receiver. RF signals are internally amplified in order to compensate for any loss that may result from splitting the signal.

When used in conjunction with the AP42 or AP62 two-channel systems, the ADS48 is able to run 8 channels of wireless on a single pair of antennas and the power supply takes up only 5 rack spaces.

SUPPLIED ACCESSORIES

• 1x ADS48 Antenna Distribution Unit with rack mount
• 2x Antennas – (see photo A below)
• 1x IEC power cable
• 4x Power Jumper Cables to provide power to individual receivers – (see photo B below)
• 8x BNC-to-BNC Coaxial Cables for pass through connection for up to 4 additional receivers (single or dual) – (see photo C below)
• 2x Coaxial cables for front mounting antennas – (see photo D below)

SPECIFICATIONS

• Frequency Range: 470 – 900 MHz
• RF Output Level (Gain): 0 dB d + or 3 dB
• Input Impedance: 50 Ohm
• Output Impedance: 50 Ohm
• Power Voltage: 100 240 V AC 50 / 60 Hz
• Output DC Voltage: +12 V DC, 800 mA maximum
• Antenna Input DC Voltage: 8 V, 150 mA maximum
• Dimensions: 19 (W) x 2 (H) x 10 (D) / 480 mm (W) x 45 mm (H) x 250 mm (D)
• Net Weight: 16 oz / 2.15 kg
