Key Features:
Nominal Diameter: 8″
Nominal Impedance: 8 OHMS
RMS Power Handling: 150 Watts
MAX Power Handling: 300W
Sensitivity: (1w/1m): 97 dB
Frequency Response: 60Hz-5KHz
Recommended Hi Pass Crossover: 80 Hz
Specifications:
Motor Specifications
Voice Coil Diameter: 1.5″ / 38.1 mm
Voice Coil Former Material: Kapton
Winding Material: Aluminum
Cone Material: Paper
Dust Cap Material: Paper
Surround Material: Cloth
Basket Material: Steel
Magnet Material: Ferrite
Magnet Weight: 20 oz
Displacement Volume: 0.61L / 0.0021ft
Thiele & Small Parameters
Equivalent Volume: 24.6L
Excursion (one way): 9.8mm
Free Air Resonance: 70 Hz
Voice Coil Inductance: 0.19 mH
DC Resistance: 6.95 ohms
Measurements
Overall Diameter: 8.07″
Overall Depth: 3.77″
Front Mount Baffle Cutout: 7.28″
Mounting Depth: 3.54″
Motor Diameter: 4.52″
