Key Features:
Nominal Diameter: 8″ RMS Power Handling: 275W MAX Power Handling: 550W Nominal Impedance: 4 Ohm Sensitivity: (1w/1m): 96 dB Frequency Response: 115Hz-16KHz Recommended Hi Pass Crossover: 120 Hz
Motor Specifications
Voice Coil Diameter: 1.5″/ 38.6 mm
Voice Coil Former Material: Kapton
Winding Material: CCAW
Cone Material: Paper
Surround Material: Cloth
Basket Material: Steel
Magnet Weight: 30 oz
Displacement Volume: .66L
Thiele & Small Parameters
Equivalent Volume: 26.60L
Excursion: 9.3mm
Free Air Resonance: 93Hz
Mechanical Factor: 9.275
Electrical Factor: 0.589
Total Factor: 0.552
CD Resistance: 3.2 Ohms
Measurements
Overall Diameter: 8.22″ / 209mm
Overall Depth: 3.38″ / 86mm
Front Mount Baffle Cutout: 7.16″ / 182 mm
Mounting Depth: 3.11″ / 79 mm
Motor Diameter: 4.72″ / 120mm
