Simple & Reliable IP Phone 1 SIP Account, 2 Line Keys, 3-Wway Conferencing GXP1615

Key Features:

• 1 SIP account
• 2 line keys
• 3-way conferencing
• 3 XML programmable context-sensitive soft keys
• Dual-switched 10/100 mbps ports
• EHS support for Plantronics headsets
• Up to 1000 contacts
• Call history up to 200 records
• Integrated PoE

Specifications:

• Protocols/Standards – SIP RFC3261, TCP/IP/UDP, RTP/RTCP, HTTP/HTTPS, ARP/RARP, ICMP, DNS (A record, SRV, NAPTR), DHCP, PPPoE, SSH, TFTP, NTP, STUN, SIMPLE, LLDPMED, LDAP, TR-069, 802.1x, TLS, SRTP, CDP/SNMP/RTCP-XR
• Network Interfaces – Dual switched auto-sensing 10/100 Mbps Ethernet ports, integrated PoE
• Graphic Display – 132 x 48 (2.95″) LCD display
• Feature Keys – 2 line keys with dual-color LED and 1 SIP account, 3 XML programmable context sensitive soft keys, 5 (navigation, menu) keys, 13 dedicated function keys for PAGE/INTERCOM, PHONEBOOK, MESSAGE, HOME, HOLD, RECORD, MUTE, HEADSET, TRANSFER, CONFERENCE, SEND and REDIAL, SPEAKERPHONE, VOLUME
• Voice Codecs – Support for G.711/a, G.722 (wide-band), G.723,G.726-32, G.729 A/B, iLBC, in-band and out-of-band DTMF (In audio, RFC2833, SIP INFO), VAD, CNG, AEC, PLC, AJB, AGC
• Telephony Features – Hold, transfer, forward (unconditional/no-answer/busy), 3-way conferen- cing, call park/pickup, downloadable phone book (XML, LDAP, up to 1000 items), call waiting, call history (up to 200 records), off-hook auto dial, auto answer, click-to-dial, flexible dial plan, hot desking, personalized music ringtones, server redundancy & fail-over Headset Jack RJ9 headset jack (allowing EHS with Plantronics headsets)
• Base Stand – Yes, 2 angled positions available, wall mountable
• Wall Mountable – Yes
• QoS – Layer 2 QoS (802.1Q, 802.1P) and Layer 3 (ToS, DiffServ, MPLS) QoS Security User and administrator level access control, MD5 and MD5-sess based authentication, 256-bit AES encrypted configuration file, TLS, SRTP, HTTPS, 802.1x media access control
• Multi-language – English, German, Italian, French, Spanish, Portuguese, Russian, Croatian, simplified and traditional Chinese, Korean, Japanese and more
• Upgrade/Provisioning – Firmware upgrade via TFTP / HTTP / HTTPS, mass provisioning using TR069 or AES encrypted XML configuration file, FTP/FTPS
• Power & Green Energy Efficiency – Universal Power Supply Input 100-240VAC 50-60Hz; Output +5VDC, 600mA; PoE: IEEE802.3af Class 2, 3.84W-6.49W; IEEE802.3az (EEE)
• Physical – Dimension: 209mm (L) x 184.5mm (W) x 76.2mm (H) (with handset) Unit weight: 0.74kg; Package weight: 1.1kg Temperature and Humidity Operation: 0C to 40C, Storage: -10C to 60C , Humidity: 10% to 90% Non-condensing
• Package Content – GXP1610/1615 phone, handset with cord, base stand, universal power supply, network cable, Quick Installation Guide, brochure, GPL License
• Compliance – FCC: Part 15 (CFR 47) Class BCE : EN55022 Class B, EN55024, EN61000-3-2, EN61000-3-3, EN60950-1RCM: AS/ACIF S004; AS/NZS CISPR22/24; AS/NZS 60950; AS/NZS 60950.1
