The SMCJ440A Transient Voltage Suppressor Diode – DO-214AB (SMC) SMD Package is designed to provide robust protection for sensitive electronics against voltage transients caused by lightning, inductive load switching, or electrostatic discharge (ESD). Its glass-passivated junction and high surge-handling capability ensure reliable and efficient clamping performance. Perfect for telecom, industrial, and power management systems requiring superior surge protection.

Features:

1. 1500W peak pulse power capability (10/1000s waveform)
2. Glass passivated chip for enhanced durability and stability
3. Low inductance structure for fast transient response
4. Excellent clamping capability with minimal voltage overshoot
5. Compliant with RoHS and UL94V-0 flammability standards

Specifications:

• Stand-off Voltage (VR): 440V
• Breakdown Voltage (VBR): 492V to 543V
• Test Current (IT): 1mA
• Clamping Voltage (VC): 713V
• Peak Pulse Current (Ipp): 2.1A
• Reverse Leakage Current (IR): 1A
• Peak Pulse Power Dissipation (PPPM): 1500W
• Peak Forward Surge Current (IFSM): 200A (8.3ms half-sine wave)
• Thermal Resistance (RJA / RJL): 75C/W / 15C/W
• Operating Junction Temperature (TJ): -55C to +150C
• Storage Temperature Range (TSTG): -55C to +150C

Package Includes:

1 SMCJ440A Transient Voltage Suppressor Diode – DO-214AB (SMC) SMD Package
