CONNECTOR(S)

External Ports

4 – USB Type-A (9 pin, 5 Gbps)

1 – USB Type-B (9 pin) USB 3.0

ENVIRONMENTAL

Operating Temperature

0 C to 50 C (32 F to 122 F)

Storage Temperature

-20 C to 60 C (-4 F to 140 F)

Humidity

5~85% RH

HARDWARE

USB-C Device Port(s)

No

USB-C Host Connection

No

Fast-Charge Port(s)

No

Ports

4

Interface

USB 3.2 Gen 1 (5Gbps)

Chipset ID

VIA/VLI – VL811+

INDICATORS

LED Indicators

1 – Power (Blue)

PACKAGING INFORMATION

Package Height

3.2 in [8.2 cm]

Package Length

8.4 in [21.4 cm]

Shipping (Package) Weight

14.5 oz [411.0 g]

Package Width

6.0 in [15.2 cm]

PERFORMANCE

Total USB Power Output

10W

Maximum Data Transfer Rate

5 Gbps

MTBF

24,000 Hours

PHYSICAL CHARACTERISTICS

Form Factor

Desktop

Weight of Product

3.0 oz [84.0 g]

Colour

Black

Material

Plastic

Product Length

3.7 in [9.5 cm]

Product Width

2.7 in [6.8 cm]

Product Height

0.9 in [2.3 cm]

POWER

Power Source

AC Adapter Included

Input Voltage

100 – 240 AC

Input Current

0.35A

Output Voltage

5 DC

Output Current

2A

Centre Tip Polarity

Positive

Plug Type

M

Power Consumption (In Watts)

10

SOFTWARE

OS Compatibility

OS Independent; No additional drivers or software required

SPECIAL NOTES / REQUIREMENTS

System and Cable Requirements

USB 3.0 or 2.0 or 1.x compliant host controller with available port.

WHAT’S IN THE BOX

Included in Package

1 – USB 3.0 Hub

1 – 3 ft [0.91 m] USB 3.0 cable

1 – Power Adapter

1 – Instruction Manual
